Capacity

20T（Traction）

25T（Traction）

30T（Traction）

35T（Traction）

55T（Traction）

Size

L*W*H

620*620*155mm

L*W*H

620*620*160mm

L*W*H

700*700*185mm

L*W*H

750*750*185mm

L*W*H

910*800*185mm

Configure

Motor:750W*2

Gearbox:6JU100L

Battery: 60Ah Ternary lithium battery

Motor:1000W*2

Gearbox:6JU100L

Battery: 60Ah Ternary lithium battery

Motor:1000W*2

Gearbox:7JU100L

Battery: 60Ah Ternary lithium battery

Motor:1500W*2

Gearbox:7JU100L

Battery: 120Ah Ternary lithium battery

Motor:2000W*2

Gearbox:7JU100L

Battery: 120Ah Ternary lithium battery

Package Size

640*640*160mm

640*680*180mm

720*720*200mm

780*780*200mm

800*920*200mm

G.W.

137KG

139KG

235KG

240KG

255KG

Wheels Size

130MM*90MM

130MM*110MM

135MM*120MM

135MM*120MM

140MM*150MM

Wheels material

Import Polyurethane

Import Polyurethane

Import Polyurethane

Import Polyurethane

Import Polyurethane

Turntable Height

20mm

20mm

20mm

20mm

20mm

Turntable Diamenter

250mm

250mm

320mm

320mm

320mm

Battery

ternary lithium battery 60AH

ternary lithium battery 60AH

ternary lithium battery 60AH

ternary lithium battery 120AH

ternary lithium battery 120AH

Gradeability

15 Degrees

15 Degrees

15 Degrees

15 Degrees

15 Degrees

Matching Rear Skate:

Note: Additional fees will be charged for Matching Rear Skate

Single row 2 wheels

Single row 3 wheels

Double row 3 wheels (a total of 6 wheels)

Double row 4 wheels (8 wheels in total)

Double row 4 wheels (8 wheels in total)

Price: FOB China USD$

$4600.00

$4900.00

$5500.00

$5800.00

$7800.00

Using Impact resistance 1300Mpa high-strength steel plate, with strong frame. 12mm Thickness.

The charging voltage is 220-260 volt
